LED Identification
To identify a WINGER LED with the help of the identification, please use the following table.
The following example of a WEEGN24-CS is decoded as follows:
WE|E|GN|24|-C|S
this corresponds to a WINGER LED, 5 mm, 20° viewing angle, green with 24000mcd in a clear case.
The first two places are always occupied with the manufacturer ID, so WE. This following table therefore explains the LED identification at the 3rd place.
Design / Construction
Colors
Brightness / Power
Package / Operation
Viewing angle
X(XXXXX)
XX(X)
X(X)
- X(X)
X
A = 1.8mm round
WW = warm white < 4000 K
Standard LED = mcd
C = waterclear
N = < 10°
B = 3mm round
CW = cold white > 7000 K
i.e. 14 = 14000mcd
D = diffuse
S = 11° to 30°
D = 4.8mm round
NW = neutral white 4000 to 5000 K
Superflux = Lm
T = coloured
W = 31° to 90°
E = 5mm round
PW = pure white 5000 to 7000 K
10mm LED = Lm
S = Star PCB
M = > 91°
F = 8mm round
Power LED = W
E = Emitter
not specified = Power LED
G = 10mm 4 Chip
YE = yellow
SMD LED = mcd
i.e. 01 = 1000mcd
i.e. 01 = 1000mcd
R = radial beam
H = 3x2mm rectangular
OR = orange
B = waterclear flashing / blinking
I = Superflux 5mm 1-Chip
CN = cyan
F = clear, slow change
J = Superflux 5mm 3-Chip
PN = pink
W = clear, fast change
K = Superflux 5mm 4-Chip
BL = blue
U = clear, fading
L = SMD 0402
RGB = RGB
H = flat top, diffuse
M = SMD 0603
RW = red / white
I = short flat top, diffuse
N = SMD 0805
RG = red / green
K = flat top, waterclear
O = SMD 1206
RB = royal blue
L = com. anode , waterclear
P = Power LED
RD = red
G = com. anode , diffuse
Q = PLCC2
DR = deep red
P = digital control
R = PLCC6
UV = UV
A possibly following number describes the version number
U = SMD 3535
IR = infrared
S = 5mm round 12 Volt
GN = green
T = 10mm round 12 Volt
COB220 = Chip on Board 220 Volt
COB8 = Chip on Board 8-Chip
COB15 = Chip on Board 15-Chip
